Specification
Specifications
- Product codeCSS610-8P-2S+OUT
- Suggested price$199.00
- Switch chip model88E6193
- Operating SystemSwOS Lite
- Storage size64 KB
- Storage typeFLASH
- MTBFApproximately 200’000 hours at 25C
- Tested ambient temperature-40°C to 70°C
Powering
- Number of DC inputs3 (2-pin terminal)
- 2-pin terminal input Voltage24-57 V (Battery 22-30 V)
- Max power consumption208 W
- Max power consumption without attachments9 W
- Cooling typePassive
PoE-out
- PoE-out portsEther1-Ether8
- PoE out802.3af/at
- Low voltage PoE-Out current limit1.0 A
- High voltage PoE-Out current limit0.64 A
- Total output power120
Ethernet
- 10/100/1000 Ethernet ports8
- Number of 1G Ethernet ports with PoE-out8
Fiber
- SFP+ ports2
Other
- CPU temperature monitorYes
- Current MonitorYes
- Voltage MonitorYes
Certification & Approvals
- CertificationCE, EAC, ROHS
- IP54
Included parts
